How to configure Cisco Phone 7911 with Elastix

How to configure Cisco Phone 7911 with Elastix

Cisco Phone 7911 looks for  term06.default.loads  file to upgrade in to SIP firmware.

Download the SIP firmware from cisco or google it and get the firmware files

Configure your TFTP server and upgrade SIP firmware.

For SIP configuration this phone support XML configuration file . SEPMACADD.cnf.xml

Continue reading How to configure Cisco Phone 7911 with Elastix

How to configure Cisco Phone 7960 or 7940 with Elastix

How to configure Cisco Phone 7960 or 7940 with Elastix

Cisco Phone 7960 or 7940 comes default with SCCP firmware you need to change the firmware to SIP .

After the SIP firmware update you need to configure these phone to work with Elastix .

Cisco Phone 7960 or 7940 does not support XML configuration file it support cnf  configuration file.

If my Phone MAC address is 0014A9713F98 then my configuration file name should be SIP0014A9713F98.cnf and place it in to Elastix server /tftpboot/ folder



I am giving simple example to configure one Extension . You can change according to your requirement.

Continue reading How to configure Cisco Phone 7960 or 7940 with Elastix

How to Configure Cisco Phone 7912G with Elastix

How to Configure Cisco Phone 7912G with Elastix

Cisco Phone 7912G comes with SCCP firmware and you have to convert it to SIP .

The easy way to convert this phone in to SIP .

1- Download the SIP firmware from Cisco or  google it and get it.

SIP Firmware Version: 8.0001
Filename: CP7912080001SIP060412A.tar

2- Extract the file and upload to Elastix   server /tftpboot/    folder

CP7912080001SIP060412A.sbin     and    gkdefault.cfg

Continue reading How to Configure Cisco Phone 7912G with Elastix

How to check software installation and uninstall by event viewer

How to check software installation and uninstall by event viewer

In the application log Event IDs  11707 and 11724  will let you know installation removal of software’s .

Event ID 11707 tells you when a install completes successfully, and also the user who executed the install package.

1- Go to Event Viewer

2- Click on Windows Logs  >  Application















Continue reading How to check software installation and uninstall by event viewer

how to stop error %Error opening tftp://255.255.255.255/ on cisco router

how to stop error  %Error opening tftp://255.255.255.255/   on cisco router

Problem: Service Configuration Error Messages

Occasionally, during bootup of Cisco hardware through Cisco IOS software, error messages similar to these are displayed:

  • %Error opening tftp://255.255.255.255/network-confg (Socket error)
  • %Error opening tftp://255.255.255.255/cisconet.cfg (Socket error)
  • %Error opening tftp://255.255.255.255/3620-confg (Socket error)
  • %Error opening tftp://255.255.255.255/3620.cfg (Socket error)

Continue reading how to stop error %Error opening tftp://255.255.255.255/ on cisco router

Cisco UCS Networking Best Practices by Brad Hedlund

Cisco UCS Networking Best Practices by Brad Hedlund

This presentation assumes familiarity with basic networking and server VNIC concepts in UCS, and familiarity with virtual port channels.

This version of the presentation (v2.5) focuses primarily on the Ethernet uplinks. SAN uplinks and VMware networking scenarios are briefly discussed but not covered extensively. Those topics and others such as QoS, the Cisco VIC, and vNIC fabric failover may be included in future versions of this presentation.

Part 1 – Cisco UCS Networking Overview

Continue reading Cisco UCS Networking Best Practices by Brad Hedlund

How to troubleshoot CallerID issues on a FXO

How to troubleshoot CallerID issues on a FXO

The Digium® X100M FXO module and X400M FXO module are daughter cards that allow Digium® analog cards to terminate analog telephone lines (POTS).

This document is intended to be a brief description of toublehsooting steps that Digium’s customers can take to resolve Caller ID issues on their Asterisk Server.

Requirements

At least one analog line.
A regular analog phone with Caller ID display feature
Fully configured Asterisk server with the latest version of DAHDI and Asterisk

Troubleshooting Steps

A Caller ID issue could be caused by several factors. This section explores the possibility that the issue could be located at the telco or by noise on the lines.
Connect an analog phone to the demarcation point. In telephony, the demarcation point is the point at which the telephone company network ends and connects with the wiring at the customer premises.
Place a call — using another line or mobile phone — from the PSTN to the analog phone connected at the demarcation point and check if the phone displays Caller ID. If the Caller ID information is not being shown by the phone, please contact your telco and ask them how to enable this feature.
Otherwise, please disconnect the phone and plug it to the line that is directly connected or closest to your Asterisk server and repeat the test call.
Continue reading How to troubleshoot CallerID issues on a FXO

How to change VCenter Server 5.5 Appliance IP address CLI

How to change VCenter Server 5.5 Appliance IP address CLI

  • Open a console session of the VCSA
  • Login as: root
  • Default password is: vmware

Execute the following command

/opt/vmware/share/vami/vami_config_net

Now you will get the option to change the network setting.

vcenter

Now you can access your server with url  https://server_ip_address:5480

Continue reading How to change VCenter Server 5.5 Appliance IP address CLI
